9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling

  • 9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling
  • 9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling
  • 9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling
  • 9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling
Place of Origin Suzhou, China
Brand Name ENG
Certification API, AISI, ISO
Model Number 435
Minimum Order Quantity 1 piece
Price USD 1000-6000 piece
Packaging Details Wooden Box
Delivery Time 8 WEEKS
Payment Terms L/C, T/T, Western Union
Supply Ability 5000PCS/Year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Diameter 9 7/8'' (251mm) Bearing Type Roller-Ball-Roller-Thrust Button/Sealed Bearing
Circulation Jet Air Connection Thread Type 6 5/8'' REG
Bit Weight 65 Kg
Highlight

Rock Roller Tooling Tricone Drill Bit

,

Mining Drilling Tricone Drill Bit

,

9 7/8 Tricone Drill Bit
Leave a Message
Product Description



9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling





  • CUTTING STRUCTURE
  • Chisel on gage, double spherical on inner rows
    Designed for very soft formations with low compressive strength and high friability such as shale, soft limestone, sandstone, gravel clay, soft dolomite, coal ore.
    Compressive strength: 6,000-9,000 psi/41-62 MPa
  •
  • SHIRTTAIL PROTECTION
  • Hard welding and wear resistant carbide protection on shirttail lip and lug



9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 09 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 1











Product Specifications
Diameter  9 7/8"  251mm
Bearing Type  Roller-Ball-Roller-Thrust Button/Sealed Bearing
Drilling cycle type  Jet Air
Connection thread ty  6 5/8'' REG
Operation Parameters
 Rotary speed (r/min)  90-120 r/min
 Weight on Bit (KN)  9,875-39,500 lbs/ 4.5-17.9 T
Air Back Pressure

 29-58 psi/0.2-0.4 MPa











About Us



        9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 29 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 3







Certifications



9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 4









Package&Shipping



9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 5

9 7/8'' IADC 435 TCI Tooth Roller Tricone Mining Drilling Bits Rock Roller Tooling 6







FAQ



Q: You are a trading company or manufacturer ?
A: Manufacturer, We are a 100% real factory with over 20 years' experience in water/oil/gas wells Drill Bits.

Q: How about your products ?
A : Both of tricone bits and PDC bits strictly conform to API 7 requirements and ISO9001. we will do kinds inspections before delivery, also cover for after-sales service.

Q: Package Methods ?
A: Normally wooden case, also can be steel box; can be customized if need.

Q: Payment Terms ?
A: we accept T/T, L/C, Paypal, Western Union, etc.

Q: Can I visit your factory ?
A: Yes, we welcome you to our factory all the time, will send invitation letters if need; also can show our workshop and warehouse online.
